MB-2, Rosewood Fingerboard, Black Hardware
The 2022 MB-2 features the original MB-1 Matt Black finish, Manson MIDI screen, Sustainiac Sustainer system and in-house designed twin P-90 hand-wound “bridge” pickups. This unique pickup set-up - the DB-90 combo - can operate as an individual pickup or combine together to give a P-90 “humbucker” type design that delivers huge tone, with a P-90 bite or supercharged in power by the activation of a push pull pot.
The tone palette is further expanded with a single coil size Sustainiac Sustainer driver that operates either as a detailed, full range, active neck pickup or when activated to the internal Sustainer electronics becomes a driver to deliver note sustain that lasts as long as the player demands. With the DB-90/Sustainiac set-up, the player has multiple tonal options. But sonic exploration is further expanded by the inclusion of the Manson MIDI Controller. Hooked up to a Digitech Whammy or Korg Kaoss pad, replicating Bellamy’s unique stage tones is merely a screen movement away.
Add in a hand signed certificate, custom figured neck options, UK produced Manson Hiscox Hardcase and you have a tour ready guitar that’s been proven on the road and in the studio.
Features:
MB V neck carve; 12” compound radius
Alder body
Maple neck
Rosewood Fingerboard
Custom X/Y MIDI Screen Controller
Sustainiac Pro
Custom Hand Wound DB-90 Bridge Pickups
Kill Button
Gotoh Hardware
Custom Hardware Volume and Tone Knobs
CTS Custom Potentiometers with Custom Taper
MB-1 Matt Black Finish
Manson Hiscox Hard Case
Matthew Bellamy Hand Signed Certificate

Body
Wood Species
Alder
Finish
MB-1 Matt Black

Neck
Material
Maple
Neck Profile
MB V
Scale Length
25.5" (648mm)
Fingerboard Material
Rosewood
Fingerboard Radius
12" (305mm)
Number of Frets
22
Nut Material
Graptech Tusq
Nut Width
1.65" (42mm)
Inlays
Side Dots

Hardware
Finish
Black
Bridge
Gotoh GTC101 with Manson Titanium Saddles
Control Knobs
Manson Custom Aluminium

Electronics
Neck Pickup
Sustainiac Stealth PRO
Bridge Pickup
2 x Manson Hand Wound DB-90 wired as a Humbucker
Controls
Kill Button, 1 x Volume, 1 x Tone (Push/Pull DB-90 Split) , 3-Way Pickup Selector Switch, Sustainiac Off/On Switch, Sustainiac Harmonic Mode Switch (Harmonic/Mix/Fundamental), Manson Custom MIDI Controller Screen
Accessories
Strings
10-46
Case
MGW Hiscox Hard Case
Other
Manson Truss Rod Adjust Tool, Gotoh H.A.P. Allen Key, Matthew Bellamy Hand Signed Certificate
